Double-sided seam welding machine for ovens
Specialized double-sided seam welding machine engineered for high-volume production of oven housings and enclosures.
Design characteristics
- Precision welding force setting min 10 daN – max 2950 daN
- Overload monitoring of diodes, thyristors and transformers
- Welding arm distance continuously variable from 0-230 mm
- Color according to desire
- Vacuum encapsulated transformers
- Cylinders in several versions
- Welding transformers power up to 1000 kVA / 50% ED
Description
This dedicated machine performs simultaneous double-sided seam welding of oven housings, ensuring continuous, leak-tight seams along both sides in a single pass. Four synchronized welding wheels with individual pneumatic actuation deliver consistent weld quality across the full length of the workpiece, dramatically reducing cycle times compared to single-sided processes.
Build quality
The robust steel frame supports four independent welding heads with their own transformers, copper bus-bar power distribution, and Festo pneumatics. Each head can be precisely aligned to match different oven dimensions, while the integrated current and force monitoring ensures repeatable, high-quality welds. The machine is engineered for demanding serial production of household and industrial oven enclosures.
Standard equipment
- Pneumatic manometer
- Height adjustment of the lower welding table with spindle and ratchet
- Built-in welding spot counter
- Overload monitoring of diodes, thyristors and transformers
- Pneumatic cylinder with adjustable approach hub and work hub
- OFF valve for electrode adjustment
- Flow sensor for cooling water
Options
- Support bar for a lower table
- Servo Welding actuator
- Built-in electrode holder
- Penetration way sensor
- Proportional valve
- HMI (Siemens or other) human-machine interface
- PLC (Siemens or other) programmable logical controller
- Remote access to the machine for easy setting up and maintaining
- Rugowsky Welding current Sensor
- Welding voltage sensor
- Welding force sensor
- Both hand safety start
- Twin foot pedal
- Adjustable working table with bristles
- Cooling water distributor with flow sensors on each circuit
- Filter for cooling water
- De-mineralization system for cooling water
- Lexan cover with lock for welding controller
