Modular Twin Spot Welder
RGS
Description
Modular welding unit, self-sufficient for single-sided double spot welding with PX1700 built-in control. Totally water-cooled. When connecting several units by cables PXCT6, it is possible to obtain either electric or pneumatic sequences, limiting total power consumption.
Standard Equipment
- ●Modular welding unit for single-sided double spot welding
- ●Built-in PX1700 control
- ●Totally water-cooled
- ●Connectable in sequence via PXCT6 cables
- ●Electric or pneumatic sequence limiting
- ●In conformity with European safety standards and directives
Technical Data
| Unit | RGS-30 | RGS-40 | |
|---|---|---|---|
| Rated output @ 50% duty cycle | kVA | 30 | 40 |
| Sec. short circuit current | kA | 19 | 23 |
| Max sec. welding current | kA | 15.5 | 18.4 |
| Duty cycle at max welding power | % | 6.7 | 4.7 |
| Electrodes force (6 bar) | daN | 185* | 185* |
| Permanent secondary current | kA | 3.3 | 3.5 |
| Secondary voltage | V | 6.7 | 8.15 |
| Nominal power supply | V | 400 | 400 |
| Nominal supply frequency | Hz | 50/60 | 50/60 |
| Delayed fuses | A | 50 | 50 |
| Water consumption | l/min | 4 | 4 |
| Compressed air pressure | bar | 6 | 6 |
| Electrodes distance | mm | 40÷150 | 40÷150 |
| Electrode diameter | mm | 20 | 20 |
| Electrodes stroke | mm | 60** | 60** |
| Weight | kg | 58 | 65 |
