Seam Welder
RK-94
Standard seam welding machine with single or double wheel drive and differential gear for precise, continuous welds.
Description
Standard seam welding machine with single or double wheel drive and differential gear for precise, continuous welds.
Key Features
- ●Single or double wheel driven with differential gear
- ●Rolls in cobalt-beryllium alloy, water-cooled
- ●Roll support heads, water-cooled
- ●Speed control with mechanical variator
- ●Speed adjustment via potentiometer drive inverter (option)
- ●In conformity with European safety standards and directives
Technical Data
| Unit | RK-94-181 | RK-94-201 | RK-94-231 | |
|---|---|---|---|---|
| Rated output @ 50% | kVA | 80 | 100 | 130 |
| Electrodes force (6 bar) | daN | 735 | 735 | 735 |
| Secondary voltage | V | 6.75 | 8.0 | 8.8 |
| Supply voltage 2 Phase | V | 400 | 400 | 400 |
| Nominal supply frequency | Hz | 50 | 50 | 50 |
| Delayed fuses | A | 140 | 180 | 230 |
| Water consumption | l/min | 10 | 10 | 10 |
| Rolls diameter | mm | 250 | 250 | 250 |
| Compressed air | bar | 6 | 6 | 6 |
| Welding capacity on mild steel | mm | 1.2+1.2 | 1.5+1.5 | 2+2 |
| Useful depth * | mm | 650 | 650 | 650 |
| Weight | kg | 18 | 23 | — |
* Different depth on request
